digital flatbed printer
--water proof, no scratch down.
easy operation and low cost digital t shirt photocopy machine
Introduction of our products:
Our products include: multifunction flatbed printer, uv flatbed printer, t-shirt printer, inks and software.
These printers can do high-quality printing on objects and materials.
We have been exporting the printers to more than 100 countries and areas. And we can provide shipping and good after-sale service to clients worldwide.
We produce different sizes multifunctional, DTG, UV printers, such as:
BYC168-1 6 colors model, 21*29.7cm,
BYC168-2.3 6 colors model, 32.9*60cm size,
BYC168-3 8 colors model, 32.9*60cm size,
BYC168-4 8 colors model, 61*175cm size,
BYC168-5A 8 colors model, 42*90cm size,
BYC168-5B 8 colors model, 42*140cm size.
BYC168-2.3 UV LED 6 colors model, 28*60cm size,
BYC168-3 UV LED 8 colors model, 28*60cm size...
These printers can print any photo/design from computer on to flat surfaces such as plastic, pvc, abs, leather, pen, CD, phone cover, golf ball, metal, wood, glass, tpu, t shirt etc.
Print costs is low, approx $1 for 1 square meter full size photo printing.
Print speed is fast, can print a4 size photo with about 1-2 minutes.
Print process is easy, directly print photos from computer onto products.
Print effect effect is high resolution, colorful, stable and strong, water proof, no scratch down.
DTG / t shirt printers can directly print photos on any color shirt;
1, for white and light color t shirt:
First put t shirt on the adapter on printer;
Then print photo from graphic software;
And then, heat press for approx 40 sec.
2, for black and dark color t shirt:
First apply fixing agent on t shirt;
Then put t shirt on the adapter on printer;
And then print photo from graphic software; print white photo first, and then print color photo to cover the white photo;
Finally, heat press for approx 40 sec.
Multifuncitonal printer use multifunctional ink and coating, to print on any flat products.
Multifunctional printer needs to apply coating on products surface, then print on them.
Multifunctional print and ink are cheap, total invest is also cheaper.
Here is specifications of the popular a3 size digital flatbed printer for reference:
|WER-3A flatbed printer|
|Printing Technology||6-color advanced MicroPiezo inkjet technology|
|Nozzle Configuration||90 nozzles*6|
|Minimum Ink Droplet Size||1.5 Pico liters|
|Print Resolution||User definable up to 5760*1440 dpi|
|Print Size||User definable up to 32*60cm|
|Print Height||User definable up to 18cm|
|Height Adjustment||Automatically by infrared ray|
|Print Speed||A4 size photo: As fast as 111 sec;|
A3 size photo: As fast as 173 sec;
Adjustable according to resolution mode.
|Ink Type||6-color ink|
|Ink Palette||Black, Cyan, Light Cyan, Magenta, Light Magenta, Yellow;|
|Ink Cartridge||Continuous Ink Supply System|
|Rated Voltage||AC 110/220 V|
|Power Consumption||Printing: Approx 35W; Sleep mode: Approx 3W|
|Interface||Hi-Speed USB 2.0|
|Operating Systems||Windows® 2000, XP, XP Professional x64 and Windows Vista™, Windows 7, Windows 8,|
Macintosh® OS X 10.2.8, 10.3.9, 10.4.11, 10.5.x and 10.6.x
|Operating Temperature||50° to 95°F (10° to 35°C)|
|Operating Humidity||20% to 80%|
|Dimensions||Net: approx 87*67*63cm;|
Packed with wooden case: approx 95*75*75cm
|Weight||Net: approx 62kg;|
Packed with wooden case: approx 87kg
|Software Included||Driver CD, Operation CD.|
The printer has some specialized advantages
phone case printer machine adopt with the most advanced MicroPiezo inkjet technology, with big print space (up to 18cm thickness), help to solve the following problems easily:
--Any material is easily to be printed;
It is easy to print full size full color photo on flat surface such as acrylic, glass, crystal, metal, PVC, ABS, leather, wood, ceramic etc; and easy to print photo or logo on products such as pen, golf ball, button, bottle, toys, CD, DVD, phone cover etc.
--One piece print is acceptable;
It prints with no need plat making, no additional cost; just directly print design from computer to surface of product.
--Thick product acceptable;
It accepts product thickness to 18cm size; you can print many big and thick products.
--Automatically multicolor print;
It adjusts colors directly by the print program and image software such as Photoshop, CorelDraw, and AI etc. No need to care about colors, the print program will make it perfect automatically.
--Good and stable print effect;
We can get permanent colorful and vibrant print effect; with water proof, no scratch down.
--Easy to operate;
Most people can operate it with 2 hours training; you can start your print business very soon.
Type: Inkjet Printer
Plate Type: Flatbed Printer
Place of Origin: Shanghai, China (Mainland)
Brand Name: WER
Usage: flatbed printer
Automatic Grade: Automatic
Color & Page: Multicolor
Gross Power: 35-200W
Dimensions(L*W*H): according to model
Weight: according to model
After-sales Service Provided: Engineers available to service machinery overseas
print technology:: digital flatbed printer
